Frame
Alpha Platinum Aluminium, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
Fork
Fox Rhythm 34, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 140 mm travel
Shock
Size: XS/S, Fox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210x52.5 mm
Size: S/M/M-L/L/XL/XXL, Fox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210x55 mm
Front wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Front hub
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Rear hub
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Spokes
DT Swiss Champion, J-Bend, Black
Tyre
Size: XS/S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.40"
Size: XS/S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60"
Size: S/M/M-L/L/XL/XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.40"
Size: S/M/M-L/L/XL/XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60"
Tyre part
Bontrager TLR valve, 50 mm
Shifter
Shimano XT M8100, 12-speed
Rear derailleur
Shimano XT M8100, long cage, 51T max cog
Bottom bracket
Shimano MT500, 92 mm, PressFit
Cassette
Shimano XT M8100, 10-51, 12-speed
Chain
Shimano SLX M7100, 12-speed
Saddle
Bontrager Arvada, hollow chromoly rails, 138 mm width
Seatpost
Size: XS/S, Bontrager Line Dropper, 100 mm travel, internal routing, 31.6 mm, 345 mm length
Size: M/M-L/L/XL/XXL, Bontrager Line Dropper, 150mm travel, internal routing, 31.6 mm, 440mm length
Handlebar
Size: XS/S, Bontrager Line, alloy, 35 mm, 27.5 mm rise, 750 mm width
Size: M/M-L/L/XL/XXL, Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width
Grips
Bontrager XR Trail Elite, alloy lock-on
Stem
Size: XS/S, Bontrager Line, 35 mm, Knock Block, 0-degree, 40 mm length
Size: M/M-L/L/XL/XXL, Bontrager Line, 35 mm, Knock Block, 0-degree, 50 mm length
Brake rotor
Shimano RT66, 6-bolt, 180 mm
