Frame
Size: XS , S
Alpha Silver Aluminium, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5 mm QR
Size: M , ML , L , XL , XXL
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
Fork
Size: XS
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: S
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Max compatible fork travel
100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear
Formula DC-31, alloy, 6-bolt, 6/7/8-speed freewheel, 135x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyre
Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.00"
Max tyre size
Frame: 29x2.20" (XS & S: 27.5x2.4") Fork: See manufacturer
Shifter
Shimano Altus EF500, 7-speed
Front derailleur
Shimano Tourney TY300, 34.9 mm clamp, down swing, down pull
Rear derailleur
Shimano Tourney TY300
Crank
Size: XS , S , M
Shimano Tourney TY301, 42/34/24, 170 mm length
Size: ML , L , XL , XXL
Shimano Tourney TY301, 42/34/24, 175 mm length
Bottom bracket
Size: XS , S , M , ML , L , XL , XXL
VP BC73, 73 mm, threaded cartridge
Size: XS , S , M , ML , L , XL , XXL
Sealed cartridge, 73mm
Cassette
Shimano TZ500, 14-28, 7--speed
Chain
KMC Z7, 7-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x/2x: 34T, 3x: 42T
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: XS , S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: XS , S
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Grips
Size: XS , S , M , ML , L , XL , XXL
Bontrager XR Endurance Comp
Size: XS , S , M , ML , L , XL , XXL
Bontrager XR Endurance Comp, lock-on
Stem
Size: XS
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: S
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Size: M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size: XL , XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Head set
Semi-integrated, 1-1/8"
Brake
Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M280 mechanical disc, 160 mm rotor
Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M281 mechanical disc, 160 mm rotor
Weight
M - 14.40 kg / 31.75 lb
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
