Frame
Alpha Platinum Aluminium, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
Fork
RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 140 mm travel
Shock
Size: XS/S, Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x52.5mm
Size: S/M/ML/L/XL/XXL, Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x55 mm
Max compatible fork travel
150mm
Front wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Front hub
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Rear skewer
Bontrager Switch thru axle
Spokes
DT Swiss Champion, J-Bend, Black
Tyre
Size: XS/S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.40"
Size: XS/S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60"
Size: S/M/ML/L/XL/XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.40"
Size: S/M/ML/L/XL/XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60"
Tyre part
Bontrager TLR valve, 50 mm
Shifter
SRAM NX Eagle, 12-speed
Rear derailleur
SRAM NX Eagle
Crank
Size: XS/S, SRAM NX Eagle, DUB, 30T steel ring, Boost (52mm chainline), 170mm length
Size: M/ML/L/XL/XXL, SRAM NX Eagle, DUB, 30T steel ring, Boost, 175 mm length
Bottom bracket
SRAM DUB, 92 mm, PressFit
Cassette
SRAM PG-1230 Eagle, 11-50, 12-speed
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: XS/S, TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M/ML/L/XL/XXL, TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 445 mm length
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 50 mm length
Brake
Size: XS/S/M/ML/L/XL/XXL, Shimano hydraulic disc, MT4100 lever, MT410 calliper
Size: XS/S/M/ML/L/XL/XXL, Shimano hydraulic disc, MT4100 lever, MT410 caliper
Brake rotor
Shimano RT56, 180 mm, 6-bolt
Weight
M - 14.11 kg / 31.10 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
