Frame
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Wheel Front
Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 100x12 mm thru axle
Wheel Rear
Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, Shimano 11/12-speed freehub, 142x12 mm thru axle
Skewer Front
Bontrager Switch chamfered thru axle, removable lever
Skewer Rear
Bontrager Switch chamfered thru axle, removable lever
Rim
Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, 100x12mm thru axle
Tyre
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28 mm
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
32 mm (as measured, see manual for details)
Charger
Charging cable included
Shifter
Shimano 105 R7170, 12-speed
Front Derailleur
Shimano 105 R7150 Di2, braze-on, down swing
Rear Derailleur
Shimano 105 R7150 Di2, 36T max cog
Crank
Size: XS, S Shimano 105 R7100, 50/34, 165 mm length Size: M Shimano 105 R7100, 50/34, 170 mm length Size: ML, L Shimano 105 R7100, 50/34, 172.5 mm length Size: XL Shimano 105 R7100, 50/34, 175 mm length
Bottom Bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano 105 7101, 11-34, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max. Chainring Size
1x: 54T, 2x: 56/43
Saddle
Size: XS, S Bontrager Aeolus Comp, steel rails, 155 mm width Size: M, ML, L, XL Bontrager Aeolus Comp, steel rails, 145 mm width
Seatpost
Size: XS, S, M Madone aero carbon seat post, 0 mm offset, short length Size: ML, L, XL Madone aero carbon seat post, 0 mm offset, long length
Handlebar
Size: XS Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width Size: S, M Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width Size: ML, L Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width Size: XL Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Stem
Size: XS Trek RCS Pro, -7-degree, 80 mm length Size: S, M Trek RCS Pro, -7-degree, 90 mm length Size: ML, L Trek RCS Pro, -7-degree, 100 mm length Size: XL Trek RCS Pro, -7-degree, 110 mm length
Brake Rotor
Shimano RT70, CentreLock, 160 mm
Rotor Size
Max brake rotor sizes: 180 mm front, 160 mm rear
Weight
ML - 8.16 kg / 17.99 lbs (with TLR sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
