Frame
500 Series OCLV Carbon, front & rear IsoSpeed, BITS internal storage, tapered head tube, internal cable routing, micro-adjust seat mast, 3S chain keeper, DuoTrap S-compatible, mudguard mounts, flat-mount disc, 142x12 mm thru axle
-
Fork
Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
-
Front Wheel
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
-
Rear Wheel
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11-speed freehub, 142x12 thru axle
-
Tire
Bontrager R2 Hard-Case Lite, aramid bead, 60 tpi, 700x32 c
-
Shifter
Shimano Ultegra R8020, 11-speed
-
Front Derailleur
Shimano Ultegra R8000, braze-on
-
Rear Derailleur
Shimano Ultegra R8000, long cage, 34T max cog
-
Crank
Size: 47
Shimano Ultegra R8000, 50/34 (compact), 165 mm length
Size: 50, 52
Shimano Ultegra R8000, 50/34 (compact), 170 mm length
Size: 54, 56
Shimano Ultegra R8000, 50/34 (compact), 172.5 mm length
Size: 58, 60, 62
Shimano Ultegra R8000, 50/34 (compact), 175 mm length
-
Bottom Bracket
Praxis, T47 threaded, internal bearing
-
Cassette
Shimano Ultegra HG800-11, 11-34, 11-speed
-
Chain
Shimano Ultegra HG701, 11-speed
-
Saddle
Bontrager Arvada Comp, steel rails, 138 mm width
-
Seatpost
Size: 47, 50, 52, 54, 56
Bontrager carbon seatmast cap, integrated light mount, 20 mm offset, 135 mm length (short)
Size: 58, 60, 62
Bontrager carbon seatmast cap, integrated light mount, 20 mm offset, 175 mm length (long)
-
Handlebar
Size: 47
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal routing, 75 mm reach, 128 mm drop, 36 cm width
Size: 50
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal routing, 75 mm reach, 128 mm drop, 38 cm width
Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal routing, 75 mm reach, 128 mm drop, 40 cm width
Size: 54, 56
Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, internal routing, 93 mm reach, 123 mm drop, 42 cm width
Size: 58, 60, 62
Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, internal routing, 93 mm reach, 123 mm drop, 44 cm width
-
Handlebar Tape
Bontrager Supertack Perf tape
-
Stem
Size: 47
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: 50
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: 52, 54
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: 56, 58
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size: 60, 62
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
-
Brake
Shimano Ultegra hydraulic disc
-
Weight
56 - 9.22 kg / 20.32 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
