Frame
100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Fork
Domane AL carbon, tapered alloy steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Front hub
Formula RX-512 alloy, 6-bolt, 100x12 mm thru axle
Rear hub
Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142x12 mm thru axle
Rim
Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve
Spokes
14 g stainless steel
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32 c
Shifter
Shimano Sora R3000, 9-speed
Front derailleur
Shimano Sora R3000, 31.8 mm clamp
Rear derailleur
Shimano Sora R3000, mid cage, 34T max cog
Crank
Size: 44, Shimano Sora R3000, 50/34 (compact), 165 mm length,
Size: 49/52/54, Shimano Sora R3000, 50/34 (compact), 170 mm length
Size: 56/58/61, Shimano Sora R3000, 50/34 (compact), 175 mm length
Bottom bracket
Shimano RS500, 68 mm, threaded external
Cassette
Shimano Sora HG400, 11-32, 9-speed
Chain
Shimano Sora HG53, 9-speed
Saddle
Size: 44/49/52, Bontrager P3 Verse Comp, steel rails, 155 mm width
Size: 54/56/58/61, Bontrager P3 Verse Comp, steel rails, 145 mm width
Seatpost
Size: 44, 49, Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length
Size: 52/54/56/58/61, Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Handlebar
Size: 44/49, Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 38 cm width
Size: 52, Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 40 cm width
Size: 54/56, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
Size: 58/61, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width
Handlebar tape
Bontrager Supertack Perf tape
Stem
Size: 44, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: 49, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: 52/54, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: 56/58, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size: 61, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Head set
FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake
Tektro C550 mechanical disc brake, dual piston, flat-mount, 160 mm rotor
Weight
56 - 10.54 kg / 23.24 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
